FMT 700 FC

The FMT 700 FC lifting tower has a structural steel base and 6082-T6 aluminium alloy sections. Designed to lift heavy loads off the ground and hold them at high altitude. This lifting tower is easy to handle, it has 4 swivel castors on the base and can pass through a door, it is also equipped with 2 rear castors for horizontal transport. Equipped with powerful stabilisers to level the lift on difficult terrain with a slight slope. Finished in black, with epoxy powder paint for extra strength. Fitted with two adjustable steel forks to support the load, whether placed on top or hooked underneath. Fitted with the safety system that engages in the more than unlikely event of a cable break.

Technical specification :

Heavy-duty lifting tower

Maximum working height: 7 m / 23 ft

Ground working wheelbase: 2.34 x 2.25 m / 7.7 x 7.4 ft

Folded dimensions: 190 79 x 55 cm

Maximum authorised load: 500 kg / 1102 lbs

Patented automatic locking system

Winch: 1150 kg

Forks

Certification: BGVC-1, DGUV 17, CE

Weight: 223 kg / 492 lbs
