Spécifications techniques :

Puissance :

2x 2500W  8 ohms
2x 4000W  4 ohms
2 x 4000W  2 ohms not recommended

Overall gain              : 34dB (50 times voltage)
Sensitivity at 8 ohms : 2.82 Vrms (+11dBu)
Signal to Noise Ratio (A weighted, 0dB) : >115dB
Frequency Response (-1dB)                  : 20 - 25 000 Hz
Typical THD (half power, 1kHz, 8 ohms) : <0.05%
Typical IMD (1kHz at 4:1, -20dB)          : <0.2%
Crosstalk (1kHz)       : > 75 dB
Slew Rate                 : >60V/us

Input Impedance      : 20 k?
Damping factor (1kHz, 8 ohms) : >800
Protections               :  Soft-Start, Short-Circuit, Over and Under-Voltage, Over-Current, Over-Load, DC Output, Temperature, SOM (Smart Overhead Management)
Operating Voltage     : 190~250VAC 50-60Hz
Preamp                    : Proprietary PureSound Circuit for unmatched sound quality (Audiophile capacitors in signal path, High Voltage Opamps, Ultra Low Noise design), Studio grade VCA limiter, Continuous protection, RF protection, Overload protection
Power Supply (PSU)  : Advanced Switch Mode with 3D-Guard tracking, 105 C long life charges capacitors
Output stage            : Fully Discrete 4th generation proprietary Class D (93% efficiency at full power)
Differential circuit for Load-Independent linear frequency response, Half bridge design with high-Speed high-Current MOSFETs, 105C Long Life capacitors
Cooling                    : Front to back airflow, Temperature regulated SUNON MagLev fans (50 000 hours dustproof), FEA optimized Radial heat-sink for maximum heat transfer

Rear Panel
Speakon Wiring
2 NEUTRIK XLR Input with latch,
2 NEUTRIK XLR Link
2 NEUTRIK Speakon NL4
Stereo / Parallel / Bridge switch

Power cable directly soldered (3x3mm²)

Speakon Wiring
SPK1 = 1+1- CH A / 2+2- CH B
SPK2 =  1+1- CH B / 2+2- Not Used

Dimensions
Chassis : 19" 2U height, 468mm total depth
Poids : 13 kgs
